Small and light Cigar and Jewellery box hinges / lightweight hinges

mini scharniere1

Our mini hinge or small piano hinge are mainly used in cigar and jewellery box as well as small wooden boxes for tools and instruments.

A perfect surface, manufactured in our own plant is imcomparable to far east manufacturers!

We make it polished - not dull !

You can get them in:

highly billiant brass plated steel with a clear baked lacquer finish
- other finish on request -



Sizes:


Open width: 9 mm - 12 mm - 14 mm - 16 mm - 18 mm
Material thickness: 0,45 mm - 0,50 mm
Pin ø: 1,15 mm
Pin material: Steel
Knuckles/Joints: 5 mm
Length:
12 up to 40 mm as well as coils / rolls of 5 m



Cigar box mini hinges in coils

back to hinges





© www.franz-holz.com   Samstag, 5. Mai 2018 14:19 Müller

Hinges finish / surface

Steel and preplated steel
Grade: DC01 C290

  • plain steel
  • nickel plated
  • brass plated
  • florentine / statuary bronzed
  • zinc plated


Stainless steel
Grade: AISI 304 & AISI 316

  • 3 D - highly brilliant
  • 3 C - mat finish


Aluminium
Grade: AlMg3

  • natural bright
  • anodized


Solid brass & plated brass
Grade: CuZn37

  • bright (pre polished)
  • nickel plated
  • florentine / statuary bronzed
